DICKLIN AWS HYDRAULIC OIL
Hydraulic Oil ISO VG 32, 46, 68,100
Hansford Dicklin AWS series is a range of premium inhibited anti-wear type hydraulic oils meeting DIN 51524 Part II performance specification and formulated from highly refined paraffinic base oil stock and fortified with selected additives to meet the requirement of major hydraulic equipment manufacturers. They have good anti-wear properties, oxidation stability and water separating properties and provide cost effective performance in modern hydraulic system working in severe condition. Effective rust and corrosion inhibitor are also include to protect the surfaces of working parts and the oil reservoir.
Hansford Dicklin AWS has been formulated to meet the requirement of many modern hydraulic systems, particularly those incorporating vane type pumps in high pressure application. Under these conditions high metal- to-metal pressures can result in a breakdown of the fluid lubricating oil film with consequent high and unacceptable wear rates. Entrained air frequently causes foaming or air release problems that can also promote premature wear and high system temperature can lead to oil oxidation and reduced service life.
VISCOSITY GRADE: DICKLIN AWS IS AVAILABLE IN FOUR (4) ISO VISCOSITY GRADES WITH THEIR TYPICAL INSPECTION.
COMPRESSOR OIL SC
SC 32, 46, 68, 100
Hansford Compressor Oil SC are premium quality oils designed primarily for the lubrication of reciprocating air compressors operating with discharge temperatures of up to 220 degrees C. It is blended from special high viscosity index base oil stock and a carefully engineered additive system which includes a special high-temperature antioxidant and corrosion and foam inhibitors. It meets European Equipment Manufacturers' requirements for low carbon forming tendency products, as well as German Standards DIN 51506, class BDL.
Hansford Compressor Oil SC is recommended for use in crankcase and cylinders of stationary, semi-portable, and portable reciprocating air or inert gs compressors, and in the compressing chamber and running gear of drip-feed rotary compressors that have similar lubricants requirements. Although Hansford Compressor Oil SC is recommended primarily for applications requiring DIN 51506 oil, the product may be used for other compressor applications for which the manufacturer recommends the use of a non-detergent rust and oxidation inhibited oil.
VISCOSITY GRADE: IS AVAILABLE IN FOUR (4) ISO VISCOSITY GRADES WITH THEIR TYPICAL INSPECTION.
SLIDEWAY OIL XT
XT 32, 46, 68, 100, 220
Hansford Slideway Oil XT is a high quality multi-purpose lubricant specially designed to provide smooth and precise movement of machine tool slideways, collets and chucks. The oil is developed with a special tackiness agent and friction modifier to improve sliding motion and eliminate stick-slip motion in heavily loaded horizontal and vertical slideways. A further advantage is the in-built protection against rust and staining which keeps exposed surfaces in a clean and bright condition.
Stick-slip or leapfrog motion of a machine tool table on its way, is most likely to occur when the table is moving slowly and subjected to heavy loads. It causes poor finish and promotes wear. Many modern machines now incorporate resin coated slideways to reduce stick-slip and the use of soluble type cutting fluids is gaining wider acceptance. Hansford Slideway Oil XT oils are formulated to provide excellent demulsibility characteristic in the presence of water based cutting fluids and have no adverse reaction to resin coated surfaces.
Hansford Slideway Oil XT 68 is classified as a heavy-medium slideway oil and Slideway Oil XT 220 as a heavy slideway oil. These oils meet the requirement of Cincinnati Milacron current P-47, P50 and P-53 Specification on slideway oils.
HANSFORD SLIDEWAY OIL XT IS AVAILABLE IN FIVE (5) VISCOSITY GRADES AS SHOWN ABOVE.
ESI-CUT 515
EMULSIFIABLE CUTTING OIL
Hansford ESI-cut is the trademark of a range of high performance general purpose metal cutting fluids which combine the chemical cutting properties of extreme pressure (EP) additives with the lubricating properties of a soluble mineral oil. They are recommended for all cutting and grinding operation where the mobility of a fluid is required.
ESI-CUT 515 is a general purpose emulsifying oil or soluble oil for use in a wide variety of metalworking operations. It is very versatile economical product possessing great durability. When mixed with water, ESI-CUT 515 form a milky-white emulsion that does not gum to machine surfaces. ESI-CUT 515 are suitable for use on a wide range of ferrous metals including brass and phosphor bronze.
CORRO-KUT S1000
CORRO-KUT SERIES RANGE OF PRODUCTS
Hansford CORRO-KUT S1000 range of products are the complete answer to metal cutting problems wherever a hand applied cutting lubricant is preferred to flood applied coolant. For beaming, tapping, drilling and screwing operation. It provides excellent lubricity characteristics extending tool life and enabling heavier cuts to be taken. Surface finish is improved and tough metals may be machined more easily with a corresponding saving in production.
A soft, low-melting point cutting lubricant paste, which contains concentrated high performance chemical additives. Hansford CORRO-KUT S1000 metal-cutting compound is applied by brush to tool cutting edges and workplace or directly from the tube. Alternatively, tools can be dipped into the compound.
DEXCON C300 CHAINSAW OIL
SUPERIOR TWO STROKE CHAINSAW OIL
Dexcon C300 Chainsaw Oil is a high performance two-stroke engine oil developed for use in all makes of air-cooled, chainsaw engines where the oil is mixed with fuel in whatever percentage as specified by the engine manufacturer. It is formulated by using the most modern additive technology together with selected paraffinic base oils to provide optimum performances.
Hansford Dexcon Chainsaw Oil C300 possesses good detergent-dispersant properties to minimize the formation of lacquers, gums and carbon deposits in the piston grooves thus ensuring that the rings stay free even a high temperatures usually attained by all air cooled chainsaw engines.
Hansford Dexcon C300 Chainsaw Oil has a medium ash content enabling high engine performances is achieved while ensuring that combustion chamber deposits and pre-ignition and fouling of spark plugs, exhaust ports and manifolds are minimized
ESI-TAP 303
METAL TAPPING FLUID
Hansford ESI-TAP 303 is a high-performance metal working fluid. It provides the industrial performance of conventional petroleum and solvent based fluids while eliminating the hazards normally associated with these traditional products.
The superior lubrication of combined with maximum heat dissipating capability at the shear plane, results in a product which extends tool life and keeps taps cool to permit rapid cutting. The additives create a strong film that can withstand extreme pressure to increase tool life and ease tapping.
THERMAL B 305
HEAT TRANSFER OIL
Hansford Thermal B 305 is a high-performance heat transfers oil designed for use in all heat transfer system and exchangers. The oil is formulated from high viscosity index paraffinic oil and fortified with special additives to provide good flow properties not only under normal operating conditions but also during low temperature start-up, when it is relatively thick and sluggish.
Hansford Thermal B 305 is recommended for use in rubber curing, plastic extrusions, dry cleaning industries and any related industries involving maximum bulk temperature of 300°C and can be increased to 320°C when used in, modern systems under carefully controlled conditions. However care should be taken to avoid film temperatures in excess of 330°C. It can also be used in open systems at much lower bulk oil temperatures.
ASHTON ROTARY COMPRESSOR OIL
HEAT TRANSFER OIL
HANSFORD ASHTON RC Series is a premium grade high-performance rotary air compressor oil that is specially developed for compressors that run up to 4,000 hours of oil life in service, even when operating at maximum discharge temperatures up to 100°C. Blended with premium semi synthetic base fluids together with an advanced technology additive package, they provide improved high-temperature stability and cleanliness, excellent low-temperature fluidity, and better overall lubricity. These characteristics help to reduce costs by extending service intervals, eliminating seasonal oil changes, and reducing power consumption.
HANSFORD ASHTON RC Series also provide excellent high varnish and deposit control, high thermal and oxidation stability for long-lasting performance, and meets or exceeds key industrial specifications.
VISCOSITY GRADE: 32, 46, 68
REDZONA SH 102
HEAVY GREASE
Hansford Redzona SH 102 is a homogenous calcium soap based which texture is smooth & buttery appearing in bright shinning red in colour. Its tackiness is a distinct added advantage in enhancing performance and extending service life.
BENEFIT
Protect against bearing wear through outstanding film strength under severe conditions of shock loading
• Resist water wash out from bearing under the most arduous conditions
• Minimize leakage from bearing at elevated temperatures
• Provides long service life through high oxidation resistance
• Resist rusting
REDZONA CFX 200
CHASSIS GREASE
Hansford Redzona CFX 200 is a calcium soap-based grease fortified with special rust inhibitors. Smooth buttery texture and shining green in color.
BENEFIT
Protect against bearing wear through outstanding film strength under severe conditions of shock loading
• Resist water wash out from bearing under the most arduous conditions
• Minimize leakage from bearing at elevated temperatures
• Provides long service life through high oxidation resistance
• Resist rusting
